We Provides Compressor Units
Carlyle compressors consistently meet and exceed the demands of challenging environments, providing the most reliable refrigeration in the world.
3 to 15 Nominal HPModel | Nominal HP |
Displ.CFM | No. of Cylinders | Suction Line Size (in) | Discharge Line Size (in) | Shipping Weight (lbs) | Oil Charge (pints) |
---|---|---|---|---|---|---|---|
06EA550 (R134A) | 20 | 50.3 | 4 | 1 5/8 | 1 1/8 | 430 | 14 |
06EA550 (R404A/R507) | 20 | 50.3 | 4 | 1 5/8 | 1 1/8 | 430 | 14 |
06EA550 (R407A) | 20 | 50.3 | 4 | 1 5/8 | 1 1/8 | 430 | 14 |
